Description
- Compact and lightweight, AIR15 active loudspeakers deliver a rich, extended low-end and natural high-frequency response in a portable enclosure that fits easily in the backseat of a small car. Powered by 1,200W (dynamic) through an efficient Class D/Class AB amplifier configuration, they provide punchy lows and clear, natural highs. Enhanced with intuitive digital tuning functions, the AIR15 gives you all the power, flexibility, and control needed for both mobile and installed sound applications.
Compact and lightweight
The AIR15 active loudspeakers deliver rich lows and natural highs in a compact enclosure. A 15-inch woofer and 1.35-inch tweeter are powered by a 1,200W amplifier, with Class D for lows and Class AB for highs. This setup ensures efficient power use and clear, natural high-frequency sound.
Inputs for a Variety of Sources
AIR full-range loudspeakers offer two XLR/TRS inputs with Class A preamps and independent gain control, plus a stereo ⅛-inch input for consumer audio. Signals mix internally and can be routed via a balanced XLR Mix output to other AIR speakers, providing flexible connectivity.
- 1.35-inch, high-frequency compression driver and 15-inch woofer with a 2.5-inch voice coil
- 900W (peak) Class D power amplifier for LF driver and 300W (peak) Class A/B amplifier for HF driver
- Maximum SPL 124 dB peak with 47 Hz to 20 kHz frequency response
- 90° x 60° (horizontal x vertical) dispersion pattern
- Onboard mixer with two combo XLR and ¼-inch inputs and one summed balanced output
- Easy-to-use DSP performance presets: DJ (music playback), FOH (normal front-of-house), Monitor (floor wedge), Speech (intelligibility)
- Additional presets and controls: Stand (pole or tripod mounting), Bracket (wall mounting), Suspend (flown applications)
- Rugged, plastic, multi-angle enclosure for mains or monitor-wedge applications, with comfortable ergonomic handle and tour-grade, 1.2 mm steel grille
- 35 mm pole socket with 7.5˚ downward tilt
- M10 rigging points for suspended installation
Configuration: 2-Way
Total Output Power: 1200 W Peak
Amplifier Power Rating:
Low Frequency (LF): 500 W Continuous / 900 W Peak
High Frequency (HF): 150 W Continuous / 300 W Peak
Amplifier Class:
LF: Class-D
HF: Class-AB
LF Driver:
1x 15″ / 38 cm Woofer
Voice Coil: 2.5″ / 6.4 cm
HF Driver: 1x 1.35″ / 3.43 cm Compression Driver
Frequency Range/Response:
40 Hz to 20 kHz (-10 dB)
45 Hz to 20 kHz (-3 dB)
Maximum SPL: 132 dB
Coverage Angle: 90° H x 60° V
Audio I/O:
2x Combo XLR-1/4″ TRS Mic/Line Input
1x 1/8″ / 3.5 mm TRS Input
1x XLR 3-Pin Mix Output
AC Input Power:
100 to 120 VAC, 50 / 60 Hz
220 to 240 VAC, 50 / 60 Hz
AC Power I/O: 1x IEC Input
Color: Black
Mounting:
Stand Mount:
1 x Dual-Angle Pole Socket – Unspecified Size
Suspension Points:
2 x Fly Point – Unspecified Thread (Top)
1 x Fly Point – Unspecified Thread (Rear)
Handles: 1x Top / 1x Side
Construction Material: Metal Grille, Polypropylene
Dimensions: 19.7 x 18.5 x 30.9″ / 50 x 47 x 78.5 cm
Weight: 46.3 lb / 21 kg
