Description
Flexible FireWire Integration
The Onyx 820i boasts seamless integration with computer recording setups, offering deep DAW compatibility. With its built-in FireWire interface, all channels, including aux sends and the master, can be routed directly into your preferred digital audio workstation (DAW). This allows for easy recording of individual tracks and simultaneous playback of stereo mixes, enhancing workflow efficiency and creative possibilities in both studio and live sound environments.
Instrument-Level DI Inputs
Equipped with instrument-level DI inputs on the first two channels, the Onyx 820i provides added versatility for recording guitars and basses directly into the mixer. With the push of a button, these inputs transform into DI inputs, ensuring optimal signal integrity and fidelity for instruments. Whether in the studio or on stage, this feature enables hassle-free integration of instruments into your mix, making it an ideal tool for musicians and engineers alike.
- 8-channel premium analog mixer with integrated 24-bit/96kHz FireWire I/O
- Qualified by Mackie for use with all major production software3 Onyx boutique-quality mic preamps
- 3-band Perkins EQ with sweepable mids on mono channels
- 3-band Perkins EQ on stereo line channels
- Hybrid mono/stereo channel with 4-band Perkins EQ
- Flexible FireWire routing, including aux sends, groups and pre/post EQ assignment for all channels
- Stereo playback from DAW, returned to control room or into channel for integration into mix
- 2 aux sends with pre/post assignment
- Built-in DI on first two channels for direct connection of guitars, bass, etc.
- Individual 48V phantom power switches on all mic inputs
- Talkback section with built in mic and flexible routing
- “Planet Earth” switching power supply for worldwide use
- Optional rack kit available
- Total Of Inputs: 8
- Mic/Line Inputs: 3 x Microphone Inputs, 5 x Line Inputs (channels 1 & 2 can be switched to Hi-Z instrument level)
- Stereo Line Inputs: 3-band Perkins EQ on stereo line channels
- AUX Sends: 2
- AUX Returns: 2 Stereo Returns
- Inserts: 2 x Channel Inserts
- 2 Trk Master I/O: 2 x Balanced XLR Outputs with Mic or Line-Level Output Button
- ALT I/O: 2 x TRS 1/4″ Alt. Output, Stereo RCA Tape Input & Output
- Monitor Outputs: 2 x Balanced TRS 1/4″ Control Room Outputs (with dedicated volume knob), 1 x Stereo 1/4″ Headphone Output (with dedicated volume knob)
- EQ Section: 2 x 4-Band EQ with Mid Sweep, 1 x 4-Band EQ, 2 x 3-Band EQ (on stereo channels)
- Solo/Mute: Yes, on every channel
- Phantom Power: Yes, +48V (on every mic channel with individual buttons)
