Description
Comprehensive Channel Control
The Mackie 2404VLZ4 24-Channel 4-Bus FX Mixer with USB offers precise control over each channel's dynamics and effects. With 20 boutique-quality Onyx mic preamps, 60mm long-wearing log-taper faders, and 128.5 dB dynamic range, it ensures pristine audio quality and smooth operation. Dedicated inline channel compression on critical inputs (channels 17-20) and four subgroups with inline compressors provide total dynamic control, while 18 dB/octave 100 Hz low-cut filters and 3-band EQ with sweepable midrange allow for precise tone shaping.
Seamless Integration and Versatile Connectivity
The Mackie 2404VLZ4 is a professional-grade mixer designed for studio recording and live sound applications. It features an integrated 4x2 24-bit USB interface, allowing simultaneous recording of up to four signals and playback of stereo mixes. With six AUX sends, two stereo returns, and four group outs, along with dedicated inline compressors and high-headroom line inputs, it offers flexible routing options for various audio sources and effects. Its universal power supply and rugged steel chassis ensure reliability and durability in any environment.
- 20 boutique-quality Onyx mic preamps
- Ultra-wide 60dB gain range
- 128.5 dB dynamic range
- +22 dBu line input handling
- Extended frequency response
- Distortion under 0.0007% (20Hz – 50kHz)
- Improved RF rejection perfect for broadcast applications
- Phantom power for condenser mics
- Dedicated inline channel compression for critical inputs (ch. 17-20)
- 20 high-headroom line inputs with dedicated inserts
- 3-band EQ with sweepable midrange
- 18 dB/oct 100Hz low-cut filter on mic input channels
- Level, pan, solo and overload/mute LEDs on each channel
- 4 subgroups featuring dedicated inline compressors for total dynamic control
- 6 aux sends with inserts, pre/post fader and internal/external FX send options
- 2 stereo returns and 4 group outs with inserts
- Dual 32-bit RMFX+™ processors featuring 24 “Gig Ready” reverbs, choruses and tap delay for live applications
- Integrated 4×2 24-bit USB interface
- Stream subgroups or master L/R to your PC or Mac for recording
- Use your favorite plug-in live via auxes 5/6
- Convenient stereo return to mains for music playback or return to channel to implement EQ, auxes and more
- PFL/AFL solo modes
- 60mm long-wearing log-taper faders
- High-resolution 12-segment stereo meters
- Sealed rotary control resist dust and grime
- “Built-Like-A-Tank” rugged steel chassis with powder-coat finish
- High-visibility, high-contrast controls deliver convenient “at-a-glance” visual feedback
- Universal power supply for worldwide use
- Type: Analog
- Channels: 24
- Connectivity: USB (4 x 2)
- Input- Mic Preamps: 20 x XLR
- Phantom Power: 20
- Inputs Line: 24 x TRS (20 x Mono, 2 x Stereo Pairs)
- Inputs-Other: 2 x RCA (Tape)
- Outputs- Main: 2 x XLR (Stereo), 1 x XLR (Mono)
- Outputs – Other: 2 x RCA (Tape), 2 x TRS (Monitor, Stereo), 1 x TRS (Monitor, Mono)
- Aux Sends: 4 x Pre/Post, 2 x Post/FX
- Send/Return I/O: 6 x TRS (Send), 4 x TRS (Stereo Returns)
- Busses/Groups: 4 x Bus
- Headphones: 1 x 1/4″
