Description
- The AT-XP5 is specially designed for the needs of DJs. This cartridge features a highly-rigid polyphenylene sulfide (PPS)/glass fiber body and a tracking force of 2 to 4 grams. It also offers a powerful output level of 5.5 mV, and its 0.3 x 0.7 mil elliptical bonded stylus tracks the record groove with high accuracy for outstanding audio reproduction. Plus, the cartridge is specifically designed to provide maximum visibility of the stylus tip.
Frequency Response: 20 – 18,000 Hz
Channel Separation: 20 dB at 1kHz
Vertical Tracking Angle: 20°
Vertical Tracking Force: 2.0 to 4.0 g (standard 3g)
Recommended Load Impedance: 47,000 ohms
Coil Inductance: 1.0 H (1 kHz)
Output Voltage: 5.5 mV (mV at 1 kHz, 5 cm/sec)
Output Channel Balance: 2.0 dB
Stylus Shape: Elliptical
Cantilever: Carbon Fibre Reinforced ABS
Static Compliance: 20 x 10-6 cm/dyne
Dynamic Compliance: 6.0×10-6cm/dyne (100Hz)
Mounting: Half-inch
Dimensions: H17.2×W17.8×D28.3mm
Accessories Included: Cartridge installation slotted screws 11.0 mm (0.43”) x 2 and 8.0 mm (0.31”) x 2,
Washer x 2, Round nut x 2, Non-magnetic screwdriver x 1Recommended Load Capacitance: 100-200 pF
Replacement Stylus: ATN-XP5
Stylus Size: 0.3 x 0.7 mil
Type: VM Dual Magnet
Weight: 6.2g
