Description
The J12a is an Active speaker featuring a 12″ LF Driver and a 1″ Compression driver This italian made speaker features a rugged gas injected molded polypropylene cabinet with a DSP processed amplifier delivering 350W + 100W RMS 128dB SPL and a standard 35mm pole mount
450 Watts of Power
The bi-amplified FBT DJ 5A active speaker features a DSP processed amp module 350W + 100W RMS – 128dB SPL and a Standard
4 DSP preset specially designed for DJ users
This preset is tailored for DJ performances in club environments, where the emphasis is on powerful bass, crisp highs, and a balanced midrange. It enhances the overall energy and impact of the music, making it well-suited for dance floors.
High efficiency switch mode power supply
A high-efficiency switch-mode power supply operates by rapidly switching the input voltage on and off. This is in contrast to linear power supplies, which regulate the output voltage by dissipating excess power as heat.
2 Way Speaker
Enhanced Signal Control: Each amplifier is optimized for its respective frequency range. Reduced Intermodulation Distortion: Separating the amplification reduces the risk of distortion between frequency bands.
- 320mm (12’’) custom woofer with improved efficiency and linearity
- 25mm (1”) HF custom compression driver
- 90°H x 60°V constant directivity horn
- 2-way bi-amplified system in Bass-Reflex
- 350Wrms class D amplifier for LF and 100Wrms for HF
- High efficiency switch mode power supply
- On-board Digital Signal processing with dynamic equalizations and protections for high SPL and high reliability
- 4 DSP preset for maximum acoustical flexibility
- Polypropylene enclosure with integrated handle
- 2 x M10 anchoring points
- 35mm Internal top hat
- Configuration: 2 Way
- Frequency response: 55Hz – 20kHz
- Low frequency woofer: 12
- High frequency driver: 1
- Maximum SPL cont/peak: 123 / 127db
- Dispersion: 90 x 60 (HxV)
- Input impedance: 8 ohm
- Crossover frequency: 2 kHz
- Input connector: 2x Speakon NL4 In & Thru
- Net Dimension (WxHxD): 410 x 663 x 387mm / 16.14 x 26.10 x 15.23in
- Net Weight: 14.1kg / 31.8lb
- Transport Dimension (WxHxD): 495 x 740 x 475mm / 19.48 x 26.10 x 18.7in
- Transport Weight: 17.2kg / 37.91lb
- AC Power requirements: 400VA
- Built-in amplifier LF/HF: 350/50W RMS
- Built-in amplifier peak LF/HF: 700/200W
- Power cord: 5m EC
