Description
Pro-Level FX Engine
Access over 50 studio-grade effects using the onboard virtual FX rack, including detailed physical models of classic gear like the 1176 compressor and Lexicon reverbs. With eight stereo FX slots and multiple graphic EQs, the X32 replaces racks of outboard gear while offering full recall and deep customization.
Motorized Faders
The X32 includes 25 motorized 100mm faders that automatically move to reflect current mix settings, allowing quick scene recalls and accurate visual feedback. Whether you're mixing live or in the studio, the automated faders provide fast access to inputs, groups, and buses, improving workflow and efficiency.
Versatile Audio Interface
With a built-in 32 x 32 USB 2.0 audio interface, the X32 easily integrates with your DAW for recording and playback. It supports popular control protocols like Mackie Control and HUI, allowing seamless fader and transport control, while maintaining ultra-low latency and high-resolution 24-bit audio at up to 48 kHz.
32 MIDAS Preamps
Enjoy pristine audio quality with 32 fully programmable MIDAS-designed mic preamps. These studio-grade preamps offer exceptional transparency and dynamic range, making them ideal for capturing everything from subtle acoustic performances to loud stage environments, with precise gain control and minimal noise.
40-input channel, 25-bus digital mixing console for Studio and Live application
32 Midas-designed, fully programmable mic preamps for audiophile sound quality
25 Fully automated motorized 100 mm faders allow for instant overview, powerful scene management and DAW control
16 XLR outputs plus 6 additional line in/outputs, 2 phones connectors and a talkback section with integrated or external mic
Individual and dynamic LCD Scribble Strips on all channels and buses creating easy assignment and intuitive channel distinction
32 x 32 channel USB 2.0 audio interface, with DAW remote control emulating HUI and Mackie Control
iPad and iPhone apps for professional remote operation available free of charge-no host PC required
High-resolution 7″ day-viewable Color TFT for easy viewing of workflow components and parameters
Main LCR, 6 matrix buses and 16 mix buses each featuring inserts, 6-band parametric EQ’s and full dynamics processing, plus 8 DCA and 6 mute groups
Virtual FX rack featuring 8 true-stereo FX slots include high-end simulations such as Lexicon 480L and PCM70, EMT250 and Quantec QRS etc.
40-Bit floating-point DSP features “unlimited” dynamic range with no internal overload and near-zero overall latency (0.8 msec)
Powerful scene management for convenient handling of complex productions
48-channel Digital Snake ready via AES50 ports, featuring Klark Teknik’s SuperMAC networking capability for ultra-low jitter and latency
USB type-A connector providing file storage and uncompressed stereo recordings plus show presets and system updates
Dedicated and easy-to-use channel strip section with direct access controls and graphic user interface for intuitive workflow
Additional user-definable control section allows for on-the-fly adjustments of your favorite parameters
ULTRANET connectivity for Behringer’s P-16 Personal Monitoring System plus AES/EBU stereo digital output and MIDI
Networked remote control for show setups with on-screen software editor via Ethernet
Built-in expansion port for audio interface cards or digital networking bridges
Future firmware updates, incl. new FX “Plug Ins”, downloadable from behringer.com free of charge
Max I/O Capacity: 40x Input / 25x Output
Number of Analog Input Channels: 32
Number of Mic Preamps: 32
Number of Analog Output Channels: 16
Faders & Level Adjustment: 25x 3.9″ / 100 mm Motorized Fader(Touch Sensitive)
Analog Inputs:
32x XLR 3-Pin Balanced Mic/Line Input
1x XLR 3-Pin Balanced Mic/Talkback Input
1x Stereo RCA Coaxial Unbalanced Aux Input
6x 1/4″ TRS Aux Return
Analog Outputs:
16x XLR 3-Pin Main/Bus Output
1x Stereo RCA Aux Output (1 Stereo Pair)
2x XLR 3-Pin Stereo Control Room/Monitor Output (1 Stereo Pair)
2x 1/4″ TRS Stereo Control Room/Monitor Output
6x 1/4″ TRS Aux Output
2x 1/4″ TRS Headphone Output
Digital I/O:
1x RJ45 Ethernet (Control, 1 Gb/s)
1x RJ45 Ultranet (I/O)
2x RJ45 AES50 (I/O)
1x XLR AES3 Output
USB I/O:
1x USB-B 2.0 (Control)
1x USB-B 2.0 (Audio Playback, Multitrack Record)
Wireless: No
Rack Mountable: No
