Description
Advanced 3-Way Design
Combines an 8" MLM woofer, a dedicated midrange driver, and the X-ART tweeter with rotatable HPS waveguide, delivering precise sound dispersion, clear mids, and deep bass for full-range audio performance in critical listening environments.
Hybrid Amplification
Utilizes Class-D amplifiers for the woofer and Class-AB amplifiers for the midrange and tweeter, offering high efficiency, low distortion, and smooth, natural audio reproduction optimized for each frequency range.
DSP Customization
Features DSP-based tuning with real-time remote control via Ethernet and A Control software, allowing users to adjust voicing, EQ, and delay settings, as well as update firmware for enhanced functionality.
Room Adaptation
Includes adjustable EQ bands for room tuning and preset voicing profiles like "Uniform Natural Response" for vibrant sound and "Pure" for accurate mixing, with Sonarworks integration for precise room calibration.
- Delivers clean, low-distortion bass with a lightweight, mineral stone-fiber cone.
- Ensures clarity by focusing on critical frequency ranges.
- Provides detailed highs with flexible, controlled dispersion.
- Combines Class-D and Class-AB amps for balanced performance.
- Offers precise tuning, updates, and remote control via Ethernet.
- Features four bands for optimizing performance in any space.
- Includes dynamic (UNR) and flat (Pure) sound options with custom EQ.
- Supports room correction for accurate monitoring.
- Enables real-time adjustments and fine-tuning from your computer.
- Reduces port noise and internal vibrations for clean sound.
- Underside mounting interface allows versatile placement.
- Covers 34 Hz to 41 kHz for full-spectrum accuracy.
- Handles up to 112 dB SPL for powerful, clear audio.
Number of Included Monitors: Single Monitor (Left Side)
Enclosure: Bass-Reflex/Ported, Shielded
Total Power Output: 340 W RMS
Tweeter: 1x 1″ / 25 mm Ribbon
Midrange:
1x 3.5″ / 8.9 cm Composite Cone
Voice Coil: 1.3″ / 33 mm
Woofer:
1x 8″ / 20.3 cm Composite Cone
Voice Coil: 1.5″ / 38.1 mm
Amplifiers:
LF: 200 W RMS / 250 W Peak Class-D
MF: 55 W RMS / 70 W Peak Class-AB
HF: 15 W RMS / 20 W Peak Class-AB
Frequency Range: 31 Hz to 45 kHz ± 0 dB (-6 dB)
Frequency Response: 34 Hz to 41 kHz ± 3 dB
Maximum Sound Pressure Level (SPL): 105 dB
Maximum Input Level: +19 dBu
Protections and Limiting: Peak Limiter, Thermal Limiting
EQ:
1x HF Shelf
1x HF Notch/Peak
1x Low-Mid Notch/Peak
1x LF Shelf
Filters: No
Crossover Frequency:
400 Hz
3 kHz
Phase Adjustment: No
App-Based Signal Processing: Yes
Maximum Sampling Rate: 96 kHz / 24-Bit
Audio I/O:
1x XLR 3-Pin Balanced Line Input (9 Kilohms)
1x RCA Unbalanced Line Input (3.3 Kilohms)
Digital Audio I/O: No
Network I/O: 1x RJ45 Ethernet
USB: No
Wireless: No
Mobile App Compatible: No
AC Input Power: 100 to 240 VAC, 50/60 Hz
Power Consumption: 500 W (Maximum)
Color: Black
Monitor Orientation: Horizontal
Enclosure Material: MDF
Mounting Points: No
Dimensions (W x H x D): 15 x 10.8 x 13″ / 38.2 x 27.4 x 32.9 cm
Weight: 36.6 lb / 16.6 kg
