Description

  • The Shure BLX288/PG58X system includes a dual-channel receiver and two handheld transmitters with PG58 capsules. It operates in specific FCC-compliant frequency bands, offers up to 300 feet of wireless range, and features QuickScan for interference-free performance. Each transmitter runs on two AA batteries for up to 14 hours.

Superior Audio Quality

Experience professional-grade sound with Shure's renowned audio performance, perfect for any vocal application or live performance.

Easy Setup with QuickScan Technology

Get up and running quickly with the BLX88 receiver’s one-touch QuickScan feature, which automatically selects the clearest frequency to minimize interference and streamline setup.

Reliable Signal with Extended Range

Operate seamlessly with a reliable wireless range of up to 300 feet (100 meters), allowing you to move freely on stage or interact with the audience without signal interruptions.

Long Battery Life

Enjoy up to 14 hours of uninterrupted performance from each BLX2 handheld transmitter, powered by just two AA batteries, ensuring long-lasting operation throughout your event.

  • The BLX88 receiver supports two transmitters, ideal for dual-microphone setups.

  • Operates up to 300 feet (100 meters) line of sight, ensuring reliable coverage.

  • One-touch QuickScan automatically selects the best frequency to avoid interference.

  • Transmitters run for up to 14 hours on two AA batteries, providing extended usage.

  • Internal antenna diversity minimizes signal dropouts and interference.

  • PG58 capsules in the transmitters are specifically designed for vocal clarity.

  • Transmitters feature an on/off switch for easy operation.

  • Supports up to 12 channels per frequency band, offering scalability for larger setups.

  • Audio Input Level:
    0 dB Gain: -20 dBV Maximum
    -10 dB Gain: -10 dBV Maximum

  • Gain Adjustment Range: 10 dB

  • RF Output: 10 mW, Typical (Varies by Region)

  • Power Requirement: 2x LR6 AA Batteries, 1.5 V Alkaline

  • Housing: Molded ABS

  • Dimensions: 2.1 x 8.8″ (53 x 224 mm)

  • Weight: 7.7 oz (218 g)

  • Type: Dynamic (Moving Coil)
  • Polar Pattern: Cardioid
  • Frequency Response: 60 Hz to 15 kHz
  • Polarity: Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of microphone output connector
  • Sensitivity: -53 dBV/Pa, (2.2 mV), 1 Pascal=94 dB SPL (@ 1 kHz)
  • Electromagnetic Hum Sensitivity: 26 dB equivalent SPL in a 1 millioersted field (60 Hz)
  • Temperature Range: -20 to 153°F (-29 to 57°C)
  • Relative Humidity: 0 to 95%

Additional information

Weight 3.66 kg
Dimensions 49 × 8.89 × 41.66 cm
