Description
- The JMaxX 112A features a 12″ LF woofer with 2″ voice coil 1″ exit throat HF compression driver with 1″ voice coil 700W RMS LF, 200W RMS HF DSP with 4-EQ pre-sets all in an incredibly lightweight gas injected moulded polypropylene cabinet. 131 dB SPL . The new FBT JMaxX 112A combines ease of use and versatility for many portable or installed sound applications: musicians, DJs, AVL contractors, rental sound reinforcement, corporate events, houses of worship, bars and clubs.
Processed 2-way active loudspeaker
A 2-way active loudspeaker is a type of audio speaker system that incorporates two separate amplifiers for its two primary components or "ways" of sound reproduction. The two ways typically refer to the speaker's ability to reproduce low-frequency sounds (bass) and high-frequency sounds (treble)
Ease of use and versatility
The new FBT JMaxX 112A combines ease of use and versatility for many portable or installed sound applications: musicians, DJs, AVL contractors, rental sound reinforcement, corporate events, houses of worship, bars and clubs.
2 DSP presets for maximum acoustical flexibility
This preset is designed to adapt to different acoustic environments by dynamically correcting the frequency response based on the characteristics of the room. It uses a combination of equalization and room analysis to optimize audio playback.
DSP with 4-EQ presets
DSP with 4-EQ presets Control panel with: XLR IN and XLR LINK, Volume, EQ presets, HP filter, GND LFT switch.
12 Inch Low Frequency Woofer and a 1″ High frequency Compression driver
2-way, bi-amplified bass reflex design cabinet
700W RMS LF, 200W RMS HF, Class D power amplifiers with switch mode power supply
DSP with 4-EQ presets
Control panel with: XLR IN and XLR LINK, Volume, EQ presets, HP filter, GND LFT switch
2 x M10 suspension points, 35mm (1.3/8”) top-hat speaker stand socket, wall bracket mount flange plate
90° Horizontal x 60° Vertical constant directivity horn
Stage monitor angling facility with 12°, 40° or 55° taper
Configuration: 2 Way
Frequency response: 48Hz – 20kHz
Low frequency woofer: 12″ (2″ VC)
High frequency driver: 1″ (1″ VC)
Maximum SPL cont/peak: 131 dB
Dispersion: 90 x 60
Input connector: XLR + 6.3mm Jack
Net Weight: 13.8kg
Built-in amplifier LF/HF: 700w/200w
Power cord: 5m IEC
