Description
Analog & Digital Fusion
Combines eight analog stereo distortion circuits with digital effects like reverb, delay, chorus, and bit reduction. The analog section features a multimode filter and a 2-band EQ, allowing deep sound shaping from subtle warmth to extreme destruction.
Customizable Effect Routing
The Flow page lets you rearrange effects, control dry/wet mix, and bypass FX blocks. Create unique signal chains for different instruments and save your settings in 512 preset slots for instant recall.
Advanced Modulation Control
Features three LFOs and an envelope generator/envelope follower, each with two assignable destinations. Add dynamic movement by modulating effects like distortion, filter cutoff, and bit reduction.make
Versatile Connectivity & Integration
Includes a 2-in/2-out USB audio interface, MIDI I/O, and CV/expression inputs. Overbridge compatibility allows seamless DAW integration, making it ideal for studio and live performance setups.
- Apply clean boost, saturation, overdrive, or heavy distortion.
- Enhance sound with reverb, delay, chorus, warble, bits, and more.
- Shape frequencies with a 7-mode filter and 2-band analog EQ.
- Rearrange effects, adjust mix levels, and bypass FX blocks.
- Use three LFOs and an assignable envelope for dynamic movement.
- Record and process audio seamlessly with 2-in/2-out USB.
- Connect via MIDI In/Out/Thru, DIN sync, and expression inputs.
- Save and recall custom effect chains instantly.
- Use as a VST/AU plug-in for DAW control and automation.
- Hands-on control in a compact, rugged build.
Compatibility: Not Specified by Manufacturer
Processor:
Sound Processing
8 × Stereo Analog Distortion Circuits
Stereo Analog Multi-Mode Filter (7 Filter Types)
2-Band Adaptable Stereo Analog EQ
Noise Gate
Reverb
Delay
Chorus
Warble
Bits
Compressor
Bass Focus
Modulation:
Assignable Envelope Generator/Envelope Follower with Two Destinations
3 × Assignable LFO (with Two Destinations per LFO)
Storage: 512 User Preset Slots
Hardware:
MIDI In/Out/Thru with DIN Sync Out
48 kHz, 24-bit D/A and A/D Converters
Hi-Speed USB 2.0 Port
Audio Outputs:
Headphones Out Level: +19 dBu Peak
Headphones Output Impedance: 36 Ohms
Impedance Balanced Main Outputs Level: +19 dBu Peak
Main Outputs Impedance: 440 Ohms Unbalanced
Audio Inputs:
Balanced Audio Input Level: +19 dBu Peak
Audio Input Impedance: 39 Kilohms
Control:
Control Inputs
Input Level: ±5 V, Accepts CV, Expression Pedals, Footswitches
Enclosure:
Sturdy Steel Casing
100 x 100 mm VESA Mounting Holes
Panel Type: OLED
Size: Not Specified by Manufacturer
Native Resolution: 128 x 64
Touchscreen: No
USB I/O: 1 x USB-B 2.0 Female Input/Output
Audio I/O:
2x 1/4″ TRS Line Output
2x 1/4″ TRS Line Input
2x 1/4″ TRS Aux/Line Input (CV/Expression Pedal Input)
1x 1/4″ TRS Headphone Output
Power Source: AC Adapter with Power Brick (Included)
AC Input Power: 100 to 240 VAC, 50 / 60 Hz
DC Input Power: 12 VDC at 2 A
Environmental Protection: No
Material of Construction: Steel
Dimensions: 8.5 x 7.2 x 2.5″ / 21.5 x 18.4 x 6.3 cm
Weight: 3.3 lb / 1.5 kg
