Description
Guitar-Ready Analogue Design
With two Hi-Z inputs, ZEDi-10 lets guitarists plug straight in without DI boxes while offering low-noise, high-headroom analogue warmth. Its musical 3-band EQ, low-cut filters, rugged build, and intuitive layout provide clear tone shaping and dependable performance on stage or in the studio.
Mixer & USB Interface
ZEDi-10 blends an analogue mixer’s hands-on control with a 24-bit/96 kHz 4×4 USB interface for easy recording, streaming, and performing. It delivers clean GSPre preamps, smooth EQ, flexible USB routing, and direct multitrack recording to Mac, PC, or iOS, making it a reliable all-in-one solution for creators.
- USB audio interface (24-bit/96 kHz)
- Cubase LE software included
- Cubasis LE App included
- 4 x mic/line Inputs with separate XLR and TRS jack sockets
- 2x stereo inputs with TRS jack sockets
- 2x guitar DI high-impedance inputs, eliminating the need for DI boxes
- 4 x high-pass filters (channels 1 through 4) for cleaning up unwanted low-frequency noise
- 3-band EQ on channels 1 through 4 enable tonal shaping
- 60mm smooth-travel fader on main mix
- 2 x XLR main outputs
- 2 x RCA monitor outputs
- 8x LED signal metering
- 48V Phantom Power for condenser mics
- Internal power supply
Max I/O Capacity: 6x Input / 8x Output
Number of Analog Input Channels: 6 (4 Mono / 1 Stereo)
Number of Mic Preamps: 4
Analog Output Channels:
1x Stereo Master Output
1x Stereo Control Room/Monitor Output
1x Mono Aux Send Output
1x Mono FX Send Output
1x Stereo Headphone Output
Mix Routing: FX Bus
Faders & Level Adjustment: 7x Channel Fader
Meters: LED
Gain/Trim Range: 5 dB to +60 dB
EQ:
Input Channels:
3-Band EQ (Mono Channels)
2-Band EQ (Stereo Channels)
Filters: 1x High-Pass: 100 Hz
Solo/Mute: Solo, Mute per Input Channel
Sample Rates: Up to 96 kHz
Bit Depth: Up to 24-Bit
Analog Inputs:
4x XLR 3-Pin Mic Input
2x 1/4″ Line/Hi-Z Input
2x 1/4″ Line Input
4x 1/4″ Line Input (2 Stereo Pairs)
Analog Outputs:
1x 1/4″ TRS Headphone Output
1x 1/4″ Aux Output
1x 1/4″ FX Output
1x Stereo RCA Monitor Output
2x XLR 3-Pin Main Output
Phantom Power: Yes
USB I/O: 1x USB-B
USB I/O Capacity: 4x Input / 4x Output
OS Compatibility: Windows / macOS
Input Power: 100 to 240 VAC
AC Input Power: 100 to 240 VAC, 50 / 60 Hz
Dimensions: 3.8 x 13.1 x 10.8″ / 96.5 x 332.7 x 274.3 mm
Weight: 4.8 lb / 2.2 kg
