Description
Enhanced Low-Frequency Response with Woven Composite Transducer
The Eris Studio 8 boasts an 8-inch woven composite low-frequency transducer that delivers Eris' signature tight, clear bass with remarkable punch. This advanced transducer, combined with 140W of Class AB biamplification, ensures efficient and powerful performance, allowing the monitor to reach an astonishing low frequency of 35 Hz without the need for a subwoofer. Experience richer low-end reproduction that adds depth and clarity to your recordings.
Wide Sweet Spot and Precise High-Frequency Reproduction
Experience unparalleled clarity and accuracy in your mixes with the Eris Studio 8's custom-designed EBM (Elliptical Boundary Modeled) waveguide. Offering a wide 120˚ horizontal dispersion and reduced desk reflections, this innovative waveguide creates a broader sweet spot for superior performance in both home studios and professional mix rooms. Combined with a 1.25-inch silk-dome high-frequency transducer, the Eris Studio 8 ensures snappy, accurate transient reproduction, capturing every detail in your recordings with unparalleled precision.
- 8-inch woven composite, low-frequency transducer
- 1.25-inch (31.75 mm), ultra-low-mass, silk-dome, high-frequency transducer
- 120˚(H) x 60˚(V) EBM waveguide for a wide sweet spot
- Front-firing acoustic port for superior bass-frequency reproduction and optimized, resonance-suppressing internal bracing
- 140W, Class AB biamplification
- 35 Hz to 20 kHz frequency response
- 106 dB SPL (Peak, @ 1 meter)
- Acoustic Tuning controls: HF (±6 dB, continuously variable); Midrange (±6 dB, continuously variable), and Acoustic Space (flat, -2, -4 dB), plus highpass filter (Off, 80 Hz, 100 Hz)
- RF interference, output-current limiting, over-temperature, transient, subsonic protection, and amplifier “soft start” feature (eliminates popping on power-up)
- Internal power supply with IEC connector and power switch with on/off LED
- Balanced XLR and ¼-inch inputs and unbalanced RCA inputs
- Voltage Requirements: 100-240 VAC, 50-60 Hz
- Connection Type: IEC
- Cabinet Material: Vinyl-Laminated, Medium-Density Fiberboard
- Protections: RF Interference
Output-Current Limiting
Over-Temperature
Turn-On/Off Transient
Subsonic Filter - Audio Switches: Acoustic Space (Flat, -2 dB, -4 dB)Low Cut (Flat, 80 Hz, 100 Hz @ -12 dB / octave)
- Audio Controls: VolumeHigh Frequency (±6 dB, center 10 kHz, continuously variable)Mid Frequency (±6 dB, center 1 kHz, continuously variable)
- Peak SOL: 106 dB (at 1 meter)
- Crossover Frequency: 3.5 kHz
- Monitor Inputs: 1- Balanced XLR, 1- Balanced 1/4” TRS, 1- Unbalanced RCA
- HF Transducers: 1.25” Ultra Low Mass, Silk Dome Tweeter
- LF Transducers: 8″ Woven Glass Fiber Composite
- Frequency Response: 35 Hz – 20 kHz
- Input Impedance: 10 kΩ
- Coverage Pattern: 120 degree (H) x 60 degree (V)
- Monitor Amplifier Power: 140W Bi-Amped
- Input Impedance: 10 kΩ
