Description
- The AudioBox GO delivers a complete, ultra-portable recording solution with all the essential connections you need for professional capture anywhere inspiration strikes. It provides Mic, Instrument, and Line inputs for versatile recording setups, along with monitor speaker and Headphone outputs for accurate playback and real-time monitoring. Powered directly via its USB-C® connection, it eliminates the need for external power supplies while ensuring reliable performance on the go. Despite its compact, pocket-sized design, the AudioBox GO retains high-quality components and studio-grade functionality, making it an ideal interface for musicians, podcasters, and content creators who need powerful recording capabilities in a lightweight, travel-friendly form factor.
Grab and Go!
AudioBox GO lets you record anywhere inspiration strikes, from tranquil lakeside guitar sessions to urban subway sampling. It's portable, versatile, and designed to turn recording into an adventure.
A Pocket-sized Dynamo
With all the connections you need to connect professional XLR vocal mics, guitars, synthesizers, headphones, and studio monitors, so it’s also fantastic for compact laptop-based studio setups where desk space is a hot commodity.
The most portable AudioBox
lets you record anything, anywhere; Mic, Line, and Instrument inputs; +48v phantom power for condenser microphones; mix control for hardware/software monitor blend; front-mounted Headphone jack; balanced stereo Main Outputs for professional studio monitors; includes Studio Magic and Studio One Prime
It's USB class-compliant
There are no special drivers or applications for you to download and install, as the device operates on standard USB class compliance, and it is fully bus-powered—so it draws power directly from your computer, eliminating the need for external adapters, extra cables, or additional power supplies.
- Ultra-affordable, ultra-compact and versatile audio interface for home and mobile recording.
- USB-C®-compatible for use with the latest devices.
- Fender Studio Pro – 6 Month Trial
- Bus-powered by your connected USB-C® device so no need for an additional power supply – works great with both Apple and Android devices.
- Connect an instrument and a microphone at the same time: One TS instrument input to record guitar or bass and one mic/line combo input to record vocals or a keyboard, drum machine or other line-level instrument.
- One ¼-inch stereo headphone output
- Mix control lets you create a custom blend between inputs and playback for monitoring recordings with zero latency.
- Two balanced TRS ¼-inch main outputs for studio monitors or other speakers.
- Professional audio quality: Studio-grade converters allow for up to 24-bit/96 kHz recording and playback assuring the highest quality possible.
- Professional XMAX-L mic preamp: Your microphone will sound its best thanks to this custom low-noise, high-headroom design with 50 dB of adjustable gain and switchable 48V phantom power for professional XLR condenser mics.
Channels of I/O: 2 Inputs / 2 Outputs
Maximum Sampling Rate: 96 kHz / 24-Bit
Number of Microphone Inputs: 1
Input Level Adjustment: 2x Knob
Gain/Trim Range:
Mic/Hi-Z Inputs: 0 to +50 dB
Line Inputs: -20 to +30 dB
Analog Audio I/O:
1x Combo XLR-1/4″ TRS Balanced/Unbalanced Mic/Line Input
1x 1/4″ TS Unbalanced Hi-Z Input
1x 1/4″ TRS Unbalanced Headphone Output (Front Panel)
2x 1/4″ TRS Balanced Monitor Output
Phantom Power: 48 V ± 2 V, Selectable On/Off
Host Connection: 1x USB-C (Class-Compliant)
Host Connection Protocol: USB 2.0
Frequency Response:
Mic Inputs: 20 Hz to 20 kHz ±3 dB
Line Outputs: 20 Hz to 20 kHz ±0.2 dB
Headphone Outputs: 20 Hz to 20 kHz ±0.5 dB
Maximum Input Level:
Mic Inputs: +10 dBu (1 kHz, 0.5% THD)
Line Inputs: +19 dB
Hi-Z Inputs: +13 dB
Headphone Output Power: 30 mW per Channel into 60 Ohms
Impedance:
Mic Inputs: 1.4 Kilohms
Line/Hi-Z Inputs: 750 Kilohms
Line Outputs: 51 Ohms
Dynamic Range:
A/D Converters: 90 dB (A-Weighted, 48 kHz Sample Rate)
D/A Converters: 102 dB (A-Weighted, 48 kHz Sample Rate)
SNR: Headphone Outputs: 90 dB (A-Weighted, 1 kHz, Max Gain)
THD+N:
Mic Inputs: < 0.004% (Unweighted, 1 kHz, Unity Gain, at +4 dBu)
Line Outputs: < 0.007% (A-Weighted, 1 kHz)
Headphone Outputs: < 0.08% (A-Weighted, 1 kHz, Max Gain)
Sample Rates: 44.1 to 96 kHz
Bit Depths: 24-Bit
Latency: Zero-Latency Direct Monitoring
Sync Sources: Internal
OS Compatibility:
Computer: macOS 10.13 or Later / Windows 10 or Later / Chrome OS
Mobile: iPadOS Only
RAM Requirements: 4 GB
Storage Requirements: 200 MB
Mobile Device Compatibility:
iPad Pro
iPad
iPad Air
iPad Mini
iPhone
iPod Touch
Android Smartphone
Android Tablet
Required Hardware:
USB Cable (Included)
Available USB-A Port
Power Requirements: USB Bus Power
Dimensions: 4.25 x 3.3 x 1.73″ / 10.79 x 8.4 x 4.39 cm
Weight: 0.5 lb / 0.2 kg
