Description
High Output Signal
The optimized 10 mV output boosts the signal-to-noise ratio, ensuring accurate timecode tracking with fewer dropouts. This makes it ideal for DVS users seeking reliable, high-fidelity performance during digital DJ sets.
Preserves Timecode Vinyl
Designed to reduce playback of frequencies that cause surface noise and wear, it extends the lifespan of timecode records. DJs benefit from cleaner signals and lower replacement costs over time.
Digital and Analog Ready
While tailored for digital systems, it also delivers excellent sound with traditional vinyl. This dual capability makes it perfect for DJs who switch between timecode and standard records without compromising audio quality.
Optimized 10 mV output for superior timecode signal accuracy.
Extended timecode vinyl lifespan with minimized decoding errors.
Reduced playback of crackle-prone frequencies (20–18,000 Hz).
Ideal for both digital (DVS) and conventional vinyl playback.
Plug-and-play design with standard tonearm compatibility.
Channel balance at 1 kHz: 1 dB
Output voltage at 1 kHz, 5cm/sec: 10 mV
Channel separation at 1 kHz: 22 dB
Tracking ability at 315Hz: 100 μm
Compliance, dynamic, lateral: 14 μm/m N
Cantilever material: Aluminium
Stylus type: Spherical diamond
Stylus tip radius: R/18/μm
Tracking force range: 3 – 5 g
Tracking force, recommended: 4 g
Internal impedance, DC resistance: 1200 Ohm
Cartridge weight: 18,5 g
Recommended load resistance: 47 kOhm
Internal inductance: 850 mH
Recommended load capacitance: 200-400 pF
Replacement stylus: Stylus CC MKII Digital
