Description

  • The NUX NCH-4 UKIYO-E is a compact vintage chorus pedal that delivers rich, classic tones through modern DSP technology. It features three iconic chorus modes—ST Chorus, SCH-1, and CE-1—each inspired by legendary analog pedals, offering a range of sounds from subtle shimmer to lush modulation. Designed to emulate the warmth of BBD chips without the noise, it supports stereo input/output and includes a USB-C port for firmware updates. With easy mode switching and a small footprint, the UKIYO-E blends analog character with modern performance in a highly versatile package.

3 Chorus Modes

Switch between ST (inspired by MXR® Stereo Chorus), SCH-1 (based on ARION®’s vintage tones), and CE-1 (replicating the warmth of the iconic BOSS® CE-1). Each mode captures the essence of classic analog chorus units, offering a wide tonal range from subtle shimmer to deep, swirling textures ideal for jazz, pop, and rock.

Analog Feel, Digital Control

Using advanced DSP that emulates the behavior of rare BBD chips, the UKIYO-E delivers warm, analog-style chorus with precise control, low noise, and stereo output. This blend of digital reliability and analog character ensures a rich, expressive performance in any setup.

  • 3 chorus models in the mini enclosure.

  • ST Chorus: Gorgeous sounding chorus.

  • SCH-1: Clean chorus to a pretty realistic Leslie effect.

  • CE-1: Special warmth of a rich jazz atmosphere.

  • Sub-division with Smart Tap Tempo.

  • True-bypass or Buffer-bypass(Trails).

  • Supports Stereo.

  • Low power consumption. (less than 100mA)

  • Analog dry signal for low noise and zero latency.

  • Input Impedance: 1MΩ

  • Output Impedance: 10kΩ

  • Dynamic Range: 103 dB

  • DSP Processing: 48KHz / 32-bit

  • A/D D/A Sampling Rate: 48KHz / 24-bit

  • Power: 9V DC(Negative tip, Optional ACD-006A adapter)

  • Current Draw: less than 100mA

  • Dimensions: 94(L)X51(W)X53(H)mm

  • Weight: 175g
