Description
- The ZEDi-8 by Allen & Heath is a compact four-channel mixer and USB interface, perfect for live mixing and instrument tracking. It features two XLR inputs, two line/instrument inputs, stereo line inputs, and supports analog-to-digital conversion. Included Cubase LE software facilitates recording and editing. Preamps modeled after the GS2-R24 ensure warmth and low noise. The mixer has on-board EQs, a high-impedance switch for guitars, a USB routing switch, a 60mm fader, LED metering, 48V phantom power, and an internal power supply, all in a portable design.
Integrated USB Audio Interface
The ZEDi-8 features a built-in USB audio interface with 24-bit/96 kHz processing, enabling seamless analog-to-digital and digital-to-analog conversion. This allows for high-quality recording, mixing, and playback, making it perfect for both live performances and studio work.
High-Quality Preamps and EQs
Equipped with preamps modeled after the renowned Allen & Heath GS2-R24, the ZEDi-8 ensures low noise, warmth, and ample headroom. Each channel includes a 2-band EQ for precise tonal shaping, enhancing the clarity and depth of your audio.
Versatile Input and Output Options
The ZEDi-8 offers a variety of input and output options, including two XLR mic/line inputs, two stereo line inputs, and two high-impedance guitar inputs. The mixer also features 2x XLR main outputs, 8x LED signal metering, and a 60mm smooth-travel fader for precise control, making it adaptable to various audio setups and environments.
Cubase LE Software Included
The mixer comes with Cubase LE, a versatile digital audio workstation (DAW) for recording, sequencing, and editing music. Whether you are working with audio or MIDI, Cubase LE provides the tools needed for professional-level music production right out of the box.
- USB audio interface (24-bit/96 kHz)
- Cubase LE software included
- Cubasis LE App included
- 2x mic/line Inputs with separate XLR and TRS jack sockets
- 2x stereo inputs with TRS jack sockets
- 2x guitar DI high-impedance inputs, eliminating the need for DI boxes
- 2x high-pass filters (channels 1 and 2) for cleaning up unwanted low-frequency noise
- 2-band EQ on channels 1 through 4 enable tonal shaping
- 60mm smooth-travel fader on main mix
- 2x XLR main outputs
- 8x LED signal metering
- 48V Phantom Power for condenser mics
- Internal power supply
Number of Analog Input Channels: 6 (2 Mono / 2 Stereo)
Number of Mic Preamps: 2
Analog Output Channels:
1x Stereo Master Output
1x Stereo Headphone OutputFaders & Level Adjustment: 5x Channel Fader
- EQ: Input Channels: 2-Band EQ
- Filters: 2x High-Pass
- Built-In Effects: No
- Sample Rates: Up to 96 kHz
- Bit Depth: Up to 24-Bit
- Analog Inputs:
2x 1/4″ TS Hi-Z Input
2x XLR 3-Pin Balanced Mic Input
2x 1/4″ TRS Balanced/Unbalanced Line/Hi-Z Input
4x 1/4″ Line Input (2 Stereo Pairs)
2x XLR 3-Pin Input - Analog Outputs:
1x 1/4″ TRS Headphone Output
2x XLR 3-Pin Balanced Main Output - Phantom Power: Yes
- USB I/O: 1x USB-B
- USB I/O Capacity: 2x Input / 2x Output
- Rack Mountable: No
- Dimensions: 3.5 x 9.8 x 9.3″ / 88.9 x 248.9 x 236.2 mm
- Weight: 3 lb / 1.4 kg
